RODE
Rode RODECaster Video S Production Console
- SKU
- RCVS
- Barcode
- 698813017393
- Broadcast Grade Video
- Studio Quality Audio
- Streaming and Recording
- Flexible Input Options
Overview
Rode RODECaster Video S Production Console by RODE, model RCVS. Listed under Video Switchers in our Video range.
Key features
- Broadcast Grade Video
- Studio Quality Audio
- Streaming and Recording
- Flexible Input Options
Buy the Rode RODECaster Video S Production Console online
Order the Rode RODECaster Video S Production Console online for €663.99, VAT included. Delivery is free to all 27 EU countries. Orders are usually dispatched within 1 to 3 working days with tracking. There are no customs charges within the EU, you can return it free of charge within 14 days, and it is covered by the two-year EU legal guarantee.
- Rode RODECaster Video S Production Console online kopen met levering in Nederland en België.
- Rode RODECaster Video S Production Console online kaufen mit Lieferung nach Deutschland und Österreich.
- Achetez Rode RODECaster Video S Production Console en ligne avec livraison en France et en Belgique.
- Compra Rode RODECaster Video S Production Console online con entrega en España.
- Compra Rode RODECaster Video S Production Console online con consegna in Italia.
- Kup Rode RODECaster Video S Production Console online z dostawą do Polski.
Specifications
Video
| Video Input Feeds | 4 simultaneous |
|---|---|
| HDMI Inputs | 3 type-A (HDMI 1.4b) |
| USB (UVC) Inputs | 1 multi-function USB-C for UVC video |
| HDMI Outputs | 1 configurable - Preview, Program, Multiview, Inputs 1 - 4 |
| Video Input Frame Rates | 1920x1080p:23.98, 24, 25, 29.97, 30, 50, 59.94, 60 (HDMI only) 1920x1080i: 25, 29.97, 30 |
| Video Output Frame Rates | 1920x1080p: 24, 25, 30, 50, 60 |
| Video Streaming Standards | 1920x1080p: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 |
| Video Engine Colour Space / Bit Depth | 4:4:4 RGB / 8-bit |
| HDMI Input Colour Space / Bit Depth | 4:4:4 RGB, 4:4:4 YUV, 4:2:2 YUV / 8, 10, 12-bit |
| USB Input Colour Space | 4:2:2 YUV, 4:2:0 YUV (NV12) |
| HDMI Output Colour Space / Bit Depth | 4:4:4 RGB, 4:4:4 YUV / 8-bit |
| USB Output Colour Space / Bit Depth | 4:2:2 YUV / 8-bit |
| Format and Frame Rate Converters | On all HDMI and USB inputs |
| NDI Protocols | Single TCP, Multicast |
| NDI Formats | Hx2, Hx3 |
| NDI Video Codecs | H.264, HEVC/H.265, 4:2:0, 8-bit |
| NDI Audio Codecs | AAC-LC, L-PCM Stereo 2.0 at 48kHz |
| NDI Interfaces | Wired Ethernet |
Switching
| Total Number of Layers | 9 simultaneous in Preview and Program |
|---|---|
| Downstream Keyers | 2 (overlays and logo) |
| Chroma Keyers (Green and Blue) | 2 |
| Luma Keyer | 1 |
| Media Players | 2 simultaneous |
| Transitions | SMPTE wipes, dip and fade |
| True Preview | Display complete scenes and overlays simultaneously in preview and program |
| Generated Borders | All scenes |
| Multiview | Program and preview Live inputs, scene and media thumbnails Audio mixer and channel status Recording, network and storage status Run time, date and time information |
| Media Player | 24GB on-board storage |
| Videos | MP4 |
| Images | PNG, JPG |
| Audio | WAV |
| Bluetooth | 5.3 (for stereo audio input or phone calls) |
Audio
| Analog Audio Inputs | 2 combo jacks (microphone, line or instrument) with Revolution Preamps™ |
|---|---|
| Wireless Audio Inputs | 2 Series IV wireless receivers |
| Digital Audio Inputs | USB 1: 2-in/2-out or multichannel (20-in) output USB 1 Chat (uses USB 1 port): 2 in/2-out with mix-minus USB 2: 2-in/2-out with MFi support USB 4: compatible with RØDE USB microphones and RØDECaster Pro II and Duo |
| Analog Audio Outputs | 2 headphone outputs (1/4-inch) |
| Audio Processing | APHEX® VoxLab™ Processing: per channel Advanced APHEX® granular processing on each channel: Compressor, Equaliser (EQ), De-esser, Panning, Noise Gate, High-pass Filter, Aural Exciter™, Big Bottom™ |
| Preamps | Frequency range: 20Hz - 20kHz Input gain: up to 76dB Input Equivalent Input Noise: -131.5dBV (A-weighted) |
| Streaming Sample Rate / Bit Depth | 48kHz / 32-bit |
| Recording Sample Rate / Bit Depth | 48kHz / 24-bit |
| Audio Mixer | 18 possible audio sources (9 stereo channels simultaneously): combo 1 and 2 (can be combined for stereo), wireless 1 and 2, video clips, sounds, HDMI 1, 2 and 3 (each can be split for two mono), Bluetooth, 3 USB audio interfaces (computers), 1 hosting USB audio device (USB microphone) 11 Outputs with Custom Routing: live mix, headphone 1, headphone 2, recording, USB 1 Chat, USB 1, USB 2, USB 4, Bluetooth, HDMI A, Network Note: Each output can be independently configured with custom level, mute status and level offset settings for each of the 9 inputs. |
Streaming, Recording & Software
| Direct Streaming | Real Time Messaging Protocol(RTMP/RTMPS) over Ethernet or Wi-Fi |
|---|---|
| Supported Platforms | Youtube Live Twitch Live Facebook Live Twitter/X Live Custom server |
| Network | Ethernet (10/100/1000 BaseT) and Wi-Fi 6 (2.4 and 5GHz) for streaming, configuration, remote control with computer and overthe-air updates |
| RØDECaster App Companion Software | Scene builder: advanced construction of scenes and remote control of device Auto-switching: configuration of automatic switching based on audio input Audio mixer: advanced configuration and control of audio sources, processing and routing Stream profiles: configuration for streaming settings and profiles Device configuration: advanced settings and customisations |
| Storage Media | External USB mass storage device (exFAT format) for recordings |
| Video Recording | Program feed as H.264/AVC MP4 file with embedded AAC stereo mix |
| Isolated (ISO) Video Recording | 4 video inputs and 1 Program feed as independent H.264/AVC files (up to 1080p30) |
| Audio Recording | Stereo mix WAV audio file |
| Multitrack Audio Recording: | 9 independent stereo WAV audio files |
| Compatible Operating Systems | macOS 11 or later Windows 10 Version 1803 or later,Windows 11 |
Physical
| Power Supply Requirements | USB-C PD 45W, 20V 2.25A |
|---|---|
| Weight (grams) | 875 |
| Length | 253.5mm |
| Width | 128.4mm |
| Height | 60.2mm |
In the box
- Rode RODECaster Video S Production Console
- Power Supply
- SuperSpeed USB-C Cable
